Throttle Body for Forklift
Forklift Throttle Body - The throttle body is a component of the intake control system in fuel injected engines so as to regulate the amount of air flow to the engine. This mechanism functions by placing pressure on the operator accelerator pedal input. Generally, the throttle body is placed between the air filter box and the intake manifold. It is usually fixed to or placed close to the mass airflow sensor. The biggest part within the throttle body is a butterfly valve known as the throttle plate. The throttle plate's main function is to be able to control air flow.
On nearly all vehicles, the accelerator pedal motion is transferred via the throttle cable, thus activating the throttle linkages works so as to move the throttle plate. In vehicles consisting of electronic throttle control, likewise called "drive-by-wire" an electric motor controls the throttle linkages. The accelerator pedal is attached to a sensor and not to the throttle body. This sensor sends the pedal position to the ECU or likewise known as Engine Control Unit. The ECU is responsible for determining the throttle opening based upon accelerator pedal position together with inputs from various engine sensors. The throttle body consists of a throttle position sensor. The throttle cable is attached to the black part on the left hand side which is curved in design. The copper coil placed next to this is what returns the throttle body to its idle position as soon as the pedal is released.
Throttle plates rotate inside the throttle body every time pressure is placed on the accelerator. The throttle passage is then opened so as to enable a lot more air to flow into the intake manifold. Typically, an airflow sensor measures this adjustment and communicates with the ECU. In response, the Engine Control Unit then increases the amount of fluid being sent to the fuel injectors to be able to produce the desired air-fuel ratio. Generally a throttle position sensor or also called TPS is fixed to the shaft of the throttle plate to provide the ECU with information on whether the throttle is in the idle position, the wide-open position or likewise called "WOT" position or somewhere in between these two extremes.
So as to regulate the least amount of air flow while idling, several throttle bodies can include valves and adjustments. Even in units which are not "drive-by-wire" there would often be a small electric motor driven valve, the Idle Air Control Valve or IACV which the ECU uses to control the amount of air that could bypass the main throttle opening.
In many automobiles it is common for them to contain a single throttle body. In order to improve throttle response, more than one can be used and connected together by linkages. High performance vehicles such as the BMW M1, together with high performance motorcycles like the Suzuki Hayabusa have a separate throttle body for every cylinder. These models are referred to as ITBs or otherwise known as "individual throttle bodies."
A throttle body is like the carburetor in a non-injected engine. Carburetors combine the functionality of the fuel injectors and the throttle body together. They work by blending the air and fuel together and by modulating the amount of air flow. Vehicles that have throttle body injection, that is known as TBI by GM and CFI by Ford, locate the fuel injectors in the throttle body. This permits an old engine the possibility to be converted from carburetor to fuel injection without really altering the engine design.
